True sine wave output (THD <3%)
Output Protections: Short circuit / Overload / Over temp. / AC circuit breaker
Input Protections: Bat. Low alarm / Bat. Low shutdown / Reverse polarity / Over Voltage
Other Features:
Wattage | 1500 | 1500 | 1500 |
Input Voltage | 10.5-15VDC | 21.0-30VDC | 42.0-60VDC |
Output Current | 0 | 0 | 0 |
Output Voltage | 230 | 230 | 230 |
Output Voltage Options | Single | Single | Single |
DC output adjustment | N/A | N/A | N/A |
Dimensions | 420 x 220 x 88 | 420 x 220 x 88 | 420 x 220 x 88 |
Working Temperature | -30~+65B0C | ||
Safety Standards | Compliance to EN60950-1 | ||
EMC Standards | Compliance to EN55022 class A (class B for TN-1500), E-Mark, EN61000-4-2,3,4,5,6,8,11, ENV50204 |
