NTN-5K is a 5000W highly reliable off-grid true sine wave DC-AC power inverter with built-in AC charger and UPS function ( AC by-pass)
Features:
Combining AC utility, battery power source and solar charger to supply AC output
AC utility charger up to 135A (Compatible to generator)
UPS function (AC by-pass) without interruption, transfer time <10ms
Can support external MPPT solar charger
True sine wave output (THD<3%)
High surge power up to 10KW
Temperature controlled cooling fan
Parallel synchronized operation up to 30KW (5+1 unit)
AC output voltage and frequency selectable by DIP S.W
Protections: Input - reverse polarity / DC low alarm / DC low shutdown / Over voltage
Output - short circuit / Overload / Over temp
Battery over discharge protection (low voltage disconnect)
-30C ~ +70c wide operating temperature
Suitable for lead-acid or li-ion batteries
Support MODBus-RTU(RS-485) communication
Conformal coating
5 years
| Wattage | 5000 | 5000 | 5000 | |
| Input Voltage | 20 ~ 33Vdc | 40 ~ 66Vdc | 280 ~ 430Vdc | |
| Output Voltage | 200/220/230/240 Vac | 200/220/230/240 Vac | 200/220/230/240 Vac | |
| Dimensions | 460*211*83.5mm (L*W*H) | 460*211*83.5mm (L*W*H) | 460*211*83.5mm (L*W*H) | |
| Working Temperature | -30 ~ +70 (Refer to “Derating curve”) | -30 ~ +70C | ||
| Safety Standards | CB IEC62368-1, , AS/NZS 62368.1, EAC TP TC 004 approved | |||
| EMC Standards | BS EN/EN55032(CISPR32) BS EN/EN55032(CISPR32) BS EN/EN61000-3-2 BS EN/EN61000-3-3 BS EN/EN61000-4-2 BS EN/EN61000-4-3 BS EN/EN61000-4-4 BS EN/EN61000-4-5 BS EN/EN61000-4-6 BS EN/EN61000-4-8 BS EN/EN61000-4-11 | |||
