PHP-3500-HV Series Enclosed Power Supplies 3500W

Download Datasheet
Models:
  • PHP-3500-115
  • PHP-3500-230
  • PHP-3500-380
Manufacturer: Mean Well
Type: Enclosed Power Supplies

PHP-3500-HV Series Features:

PHP-3500-HV series is a 3500W single-output slim type power supply with 60mm of low profile design. Adopting the full range 90~264VAC input, the entire series provides an output voltage line of 115V, 230V and 380VDC.

Features:

  • High voltage output (115/230/380V DC)
  • Slim and low profile (60mm)
  • Fanless design with water or conduction cooling
  • Active PFC design and efficiency up to 96%
  • Built-in PMBus communication protocol, CANBus optional
  • Output voltage and constant current level programmable
  • Protections: Short circuit/ Overload/ Over voltage/ Over temperature
  • Built-in remote ON/OFF control and DC-OK active signal
  • Optional water-cooling plate for quick installation
  • OVC III operating altitude up to 2000 meter
  • LED indicator for power on
  • 5 years warranty
Wattage 3500 3500 3500
Input Voltage 90~264VAC 90~264VAC 90~264VAC
Output Current 25.2 15.2 9.2
Output Voltage 115 230 380
Dimensions 380*141.4*60mm 380*141.4*60mm 380*141.4*60mm
Working Temperature -30~+70°C
Safety Standards UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 arrpoved; design refers to BS EN/EN61558-1, BS EN/EN60335-1
EMC Standards EN55032 (CISPR32), EN61000-3-12, EN61000-3-3
