| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Enclosed Power Supplies |
Global certificates in multi-fields (ITE 62368-1, Medical 60601-1, Household 60335-1, Industrial 61558-1/2-16/61010-1/-2-201, Energy converter 62477-1, SEMI F47 at 200Vac)
200% peak power capability
High efficiency up to 93%
Output voltage 0~120% and output current 0~100% programmable
Current sharing up to 9600W (3+1) for parallel use
Built in ORing MOS By request, Order NO. : NSP-2400-xxOR/MODOR
CANBus (Built in) or MODBus protocol (By request)
-40~85°C wide range operation temperature (> +60°C derating)
Extremely low leakage current <500uA, 2 × MOPP, suitable for BF medical applications
Built-in constant current limiting circuit
Protections: Short circuit / Overload / Over voltage / Over temperature
Built-in remote ON/OFF control / Remote Sense / DC OK signal
Auxiliary 5Vdc and 12Vdc
Over voltage category III (OVC III)
Operating altitude up to 5000 meters
Built-in intelligent fan speed control, low noise <46dB
Conformal coating
5 years warranty
| Wattage | 2200 | 2200 | 2400 | 2397 | 2397 | 2400 | 2400 |
| Input Voltage | 85-305Vac / 250-431Vdc | 85-305Vac / 250-431Vdc | 85-305Vac / 250-431Vdc | 85-305Vac / 250-431Vdc | 85-305Vac / 250-431Vdc | 85-305Vac / 250-431Vdc | 85-305Vac / 250-431Vdc |
| Output Current | 183.3A | 146.7A | 100A | 88.8A | 66.6A | 50A | 40A |
| Output Voltage | 12V | 15V | 24V | 27V | 36V | 48V | 60V |
| Dimensions | 325.8*107*41mm | 325.8*107*41mm | 325.8*107*41mm | 325.8*107*41mm | 325.8*107*41mm | 325.8*107*41mm | 325.8*107*41mm |
| Working Temperature | -40 ~ +85℃ (Refer to "Derating Curve") | ||||||
| Safety Standards | CB DEKRA UL CQC BSMI EAC SEMI F47 KC/BIS IEC62368-1, IEC60335-1, IEC61558-1/-2-16, IEC61010-1/-2-201, IEC60601-1; IEC62477-1 BS EN/EN62368-1, BS EN/EN60335-1, BS EN/EN61558-1/-2-16, BS EN/EN61010-1/-2-201, BS EN/EN60601-1(3.2 Version);BS EN/EN62477-1 UL62368-1, ANSI/AAMI ES60601-1(3.2 Version),UL61010-1/-2-201 GB4943.1 CNS15598-1 TP TC 004 approved KC 62368-1 and BIS IS 13252(Part 1) certified, | ||||||
| EMC Standards | BS EN/EN55035(CISPR35),BS EN/EN61000-6-2(IEC61000-6-2),BS EN/EN60601-1-2(IEC60601-1-2), BS EN/EN55014-2(CISPR14-2),KS C 9835,SEMI F47 tested at 200Vac | ||||||
