NSP-100 Enclosed Power Supplies 99.9–102W

NSP-100 Features:

The NSP-100 series is a 100W AC/DC power supply with PFC function, designed for high reliability and suitable for multiple industries.

Features:

• 85~305Vac input with PFC(277Vac available)
• No load power consumption<0.5W by R.C.
• Global certificates in multi-fields
• 200% peak power capability (12~60V)
• High efficiency up to 92%
• -40~85C wide range operation temperature (>+60C derating)
• Extremely low leakage current <350uA, 2 x MOPP, suitable for BF medical applications
• Built-in constant current limiting circuit
• Protections: Short circuit / Overload / Over voltage / Over temperature
• Fanless design for noise sensitive applications
• Built-in remote ON/OFF control
• Over voltage category III (OVC III)
• Operating altitude up to 5000 meters
• Conformal coating
• 5 years warranty
