MEAN WELL MEAN WELL logo

NPP-1700 Series Chargers 1428–1680W

Download Datasheet
Models:
  • NPP-1700-12
  • NPP-1700-24
  • NPP-1700-48
Manufacturer: MEAN WELL
Type: Chargers

NPP-1700 Series Features:

NPP-1700 is a miniaturizes dual-purpose charger and power supply.

Features:

  • Multi-function single unit battery charger or power supply operation modes selectable
  • Ultra-wide output voltage (10.5~21V, 21~42V, 42~80V)
  • Output voltage and current adjustable via potentiometer
  • 3-stage charging curve for charging mode
  • -30~+70oC wide operating temperature
  • Thermal controlled DC fan for noise reduction
  • Multiple protections: Short circuit / Over load / Over voltage / Over temperature
  • Suitable for lead-acid or li-ion batteries
  • Carry handle accessory available (Order No.: DS-Carry handle)
  • Safety approval: CB, UL, DEKRA, EAC, CE, UKCA (62368-1 + 60335-1/-2-29)
  • 3-year warranty
Wattage 1428 1680 1680
Input Voltage 90~264VAC 90~264VAC 90~264VAC
Output Current 85 50 25
Output Voltage Options 10.5~21 21~42 42~80
Dimensions 300x184x70mm 300x184x70mm 300x184x70mm
Working Temperature -30~70°C
Safety Standards CB IEC62368-1, IEC60335-1/2-29, Dekra BS EN/EN62368-1, BS EN/EN60335-1/2-29, UL62368-1, EAC TP TC 004 approved
EMC Standards BS EN/EN55032 (CISPR32), BS EN/EN55014-1
