NPP-1200 Series Chargers 1176–1209.6W

NPP-1200 Series Features:

NPP-1200 is a miniaturized dual-purpose charger and power supply.

Features:

Multi-function single unit battery charger or power supply operation modes selectable
Output voltage and current adjustable via potentiometer
3-stage charging curve for charging mode
-30~70°C wide operating temperature
Multiple protections: Short circuit/ Over load/ Over voltage/ Over temperature
Thermal controlled DC fan for noise reduction
Remote ON/OFF control
Comply with 62368-1+60335-1/2-2-29 dual certification
Suitable for lead-acid (Pb) batteries
Carry handle accessory available
3 years warranty

Spec	NPP-1200-12	NPP-1200-24	NPP-1200-48
Wattage	1176	1209.6	1209.6
Input Voltage	90~264VAC	90~264VAC	90~264VAC
Output Current	70	36	18
Output Voltage Options	Boost charge voltage 14.4V, Float charge voltage 13.8V	Boost charge voltage 28.8V, Float charge voltage 27.6V	Boost charge voltage 57.6V, Float charge voltage 55.2V
Dimensions	250x158x67mm	250x158x67mm	250x158x67mm
Working Temperature	-30~70°C
Safety Standards	CB IEC62368-1, IEC60335-1/2-29, Dekra BS EN/EN62368-1, BS EN/EN60335-1/2-29, UL62368-1, EAC TP TC 004 approved
EMC Standards	BS EN/EN55032(CISPR32), BS EN/EN55014-1, BS EN/EN61000-3-2, BS EN/EN61000-3-3
