Eaglerise
LS-150-24 DALI2 LI Constant Voltage LED Drivers
Download Datasheet
| Models: |
|
| Manufacturer: | Eaglerise |
| Type: | Constant Voltage LED Drivers |
LS-150-24 DALI2 LI Features:
LS-150-24 DALI2 LI is a 150W constant voltage LED driver that operates from 198-264Vac input with 24V output voltage.
■Features
Class II, SELV, independent
Input Voltage 220-240VAC
Protections: SCP/OLP/OVP
Power Factor>0.95
Efficiency ≥89%
Support DALI II, Push Dimming
5 years warranty
| Wattage | 150 |
|---|---|
| Input Voltage | 220~240VAC |
| Output Current | 6.25A |
| Output Voltage | 24±1VDC |
| Dimensions | 290X45X30.5(LXWXH)mm |
| Working Temperature | -20~+45°C |
| Safety Standards | EN 61347-1; EN61347-2-13; EN62384 |
| EMC Standards | EN55015; EN61000-3-2 Class C; EN61000-3-3 |
