| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | DC-DC Power Supplies |
4:1 wide input range
Protections: Short Circuit / Overload / Over voltage
Other Features:
| Wattage | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | |
| Input Voltage | 9.2~36 | 9.2~36 | 9.2~36 | 9.2~36 | 18~72 | 18~72 | 18~72 | 18~72 | |
| Output Current | 1200 | 1000 | 420 | 330 | 1200 | 1000 | 420 | 330 | |
| Output Voltage | 3.3 | 5 | 12 | 15 | 3.3 | 5 | 12 | 15 | |
| Output Voltage Options | Single | Single | Single | Single | Single | Single | Single | Single | |
| DC output adjustment | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | |
| Dimensions | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | 40.6 x 25.4 x 8.3 | |
| Working Temperature | -25~+70°C | ||||||||
| Safety Standards | IEC60950-1 CB approved by TUV | ||||||||
| EMC Standards | EN55022 Class B, EN61000-4-2,3,4,5,6,8 | EN55022 class B, EN61000-4-2,3,4,5,6,8 | |||||||
