| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | DC-DC Power Supplies |
Features
• DIP "1x1" package with industry standard pinout
• 8:1 (9~75Vdc) ultra-wide input range
• Operating temperature range -40 ~ +90℃
• No minimum load required
• Comply to BS EN/EN55032 radiated Class A without additional components
• High efficiency up to 88%
• Protections: Short circuit (Continuous) / Overload / Over voltage / UVLO
• 1.5KVdc I/O isolation
• Remote ON/OFF control
• Triming output (±10%)
• 3 years warranty
| Wattage | 20 | 20 | 20 | 20 | 20 | 20 |
| Input Voltage | 9~75V | 9~75V | 9~75V | 9~75V | 9~75V | 9~75V |
| Output Current | 0-4500mA | 0-4000mA | 0-1670mA | 0-1330mA | ±0~830mA | ±0~660mA |
| Output Voltage | 3.3V | 5V | 12V | 15V | ±12V | ±15V |
| Dimensions | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) |
| Working Temperature | 40 ~ +90℃ (Refer to "Derating Curve") | |||||
| Safety Standards | EAC TP TC 020/2011 approved | |||||
| EMC Standards | BS EN/EN55032(CISPR32) | |||||
