N78 Series DC-DC Power Supplies W

Download Datasheet
Models:
  • N7803-1PV
  • N7803-1PH
  • N7803-1C
  • N7803-1CW
  • N7805-1PV
  • N7805-1PH
  • N7805-1C
  • N7805-1CW
  • N7809-1PV
  • N7809-1PH
  • N7809-1C
  • N7809-1CW
  • N7812-1PV
  • N7812-1PH
  • N7812-1C
  • N7812-1CW
  • N7815-1PV
  • N7815-1PH
  • N7815-1C
  • N7815-1CW
Manufacturer: MEAN WELL
Type: DC-DC Power Supplies

N78 Series Features:

N78 series converters is high efficiency switching regulators can suit to replace LM78xx/LM79xx linear egulators and its pin-out can be compatible with LM78xx/LM79xx IC.

Features:

  • Compact size
  • Pin-out compatible with LM78xx/LM79xx linear regulators
  • High efficiency up to 96%, no heatsink required
  • Wide input range up to 36V
  • Support negative output
  • Operating temperature range -40~85°C
  • Comply to BS EN/EN55032 radiated Class B without additional components
  • Protections: Short circuit/ Overload/ Over temperature
  • Low ripple and noises
  • 3 years warranty
Input Voltage 12V(6~36V) 12V(6~36V) 12V(6~36V) 12V(6~36V) 12V(8~36V), 12V(8~27V) 12V(8~36V), 12V(8~27V) 12V(8~36V), 12V(8~27V) 12V(8~36V), 12V(8~27V) 24V(13~36V) 24V(13~36V) 24V(13~36V) 24V(13~36V) 24V(16~36V), 12V(8~20V) 24V(16~36V), 12V(8~20V) 24V(16~36V), 12V(8~20V) 24V(16~36V), 12V(8~20V) 24V(20~36V), 12V(8~18V) 24V(20~36V), 12V(8~18V) 24V(20~36V), 12V(8~18V) 24V(20~36V), 12V(8~18V)
Output Current 0~1000mA 0~1000mA 0~1000mA 0~1000mA 0~1000mA, 0~500mA 0~1000mA, 0~500mA 0~1000mA, 0~500mA 0~1000mA, 0~500mA 0~1000 0~1000 0~1000 0~1000 0~1000mA, 0~300mA 0~1000mA, 0~300mA 0~1000mA, 0~300mA 0~1000mA, 0~300mA 0~1000mA, 0~300mA 0~1000mA, 0~300mA 0~1000mA, 0~300mA 0~1000mA, 0~300mA
Output Voltage 3.3V 3.3V 3.3V 3.3V 5V- -5V 5V- -5V 5V- -5V 5V- -5V 9 9 9 9 12V, -12V 12V, -12V 12V, -12V 12V, -12V 15V, -15V 15V, -15V 15V, -15V 15V, -15V
Dimensions Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm Open frame size: 10.5x7.5x16mm, Case size: 11.5x9x17.5mm
Working Temperature -40~85°C
Safety Standards EAC TP TC 004 approved
EMC Standards BS EN/EN55032(CISPR32)
