XLG-50-DA2 Series DALI-2 Constant Current LED Drivers 50W

Download Datasheet
Models:
  • XLG-50-L-DA2
  • XLG-50-H-DA2
Manufacturer: MEAN WELL
Type: Constant Current LED Drivers

XLG-50-DA2 Series Features:

XLG-50-DA2 series is a 50W AC/DC LED driver featuring the constant power mode output.

Features:

  • Constant power mode output
  • Metal housing design with functional ground
  • Built-in active PFC function
  • Class 2 power unit (except for L type)
  • Standby power consumption <0.5W
  • IP67 rating for indoor or outdoor installations
  • Surge protection with 6KV-4KV
  • DALI-2 dimming with minimum level 8%
  • India (EESL) version with input over voltage protection can survive input voltage stress of 440VAC for 48 hours
  • Typical lifetime >50000 hours
  • 5 years warranty
Wattage 50 50
Input Voltage 90~305VAC 90~305VAC
Output Current 700mA 1050mA
Output Voltage 160V 60V
Dimensions 105*63*30mm (L*W*H) 105*63*30mm (L*W*H)
Working Temperature Tcase=-40 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
Safety Standards UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC AS/NZS IEC BS EN/EN61347-1, AS/NZS BS EN/EN61347-2-13 independent, BS EN/EN62384; IP67; GB19510.1, GB19510.14, EAC TP TC 004 approved
EMC Standards BS EN/EN55015(CISPR15) ,GB/T17743, BS EN/EN61000-3-2 ,GB/T17625.1, BS EN/EN61000-3-3
