XLC-60 Series (constant current non dim) Non-dim Constant Current LED Drivers 60W

Download Datasheet

XLC-60 Series (constant current non dim)

Models:	XLC-60-H XLC-60-H-N XLC-60-H-S XLC-60-H-SN
Manufacturer:	MEAN WELL
Type:	Constant Current LED Drivers

XLC-60 Series (constant current non dim) Features:

XLC-60 Series is a 60W with constant power and constant current output LED driver

Features:

- Constant power mode output with multiple stage selectable by DIP switch or NFC setting (H-type)
- Plastic housing with class II and PFC design
- Meet UL8750 Class 2 / Class P power unit
- Flicker free, complying with CE ErP directive
- Standby power consumption <0.5W
- Meet emergency lighting (EL) application
- 5 years warranty

Spec	XLC-60-H	XLC-60-H-N	XLC-60-H-S	XLC-60-H-SN
Wattage	60	60	60	60
Input Voltage	100 ~ 305VAC	100 ~ 305VAC	100 ~ 305VAC	100 ~ 305VAC
Output Current	1400mA	1400mA	1400mA	1400mA
Output Voltage	60V	60	60V	60V
Dimensions	176 X 45 X 32 mm	176 X 45 X 32 mm	176 X 45 X 32 mm	176 X 45 X 32 mm
Working Temperature	-25~90℃
Safety Standards	UL8750(Class P), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13(EL) appendix J suitable for emergency installations(DC input 176-280VDC); BS EN/EN62384 , BIS IS15885(Part2/Sec13)(NOTE 13), GBT195101, GBT19510213, EAC TP TC 004 approved; Design refer to AS/NZS 61347-1, AS/NZS 61347-2-13
