HVGC-65-B Series 0-10V Dimmable Constant Current LED Drivers 65W

Download Datasheet
Models:
  • HVGC-65-350B
  • HVGC-65-500B
  • HVGC-65-700B
  • HVGC-65-1050B
Manufacturer: Mean Well
Type: Constant Current LED Drivers

HVGC-65-B Series Features:

Constant current design

Wide input range 180~528VAC

Three in one dimming function (0~10Vdc or 10V PWM signal or resistance)

Protections: Short circuit/ Over current/ Over voltage/ Over temperature

Other features:

  • Built-in active PFC function
  • High efficiency up to 90.5%
  • Cooling by free air convection
  • IP67 design for indoor or outdoor installations
  • Suitable for LED lighting and street lighting applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry/ damp/ wet locations
  • 5 year warranty
Wattage 65 65 65 65
Input Voltage 180~528VAC, 254~747VDC 180~528VAC, 254~747VDC 180~528VAC, 254~747VDC 180~528VAC, 254~747VDC
Output Current 350mA 500mA 700mA 1050mA
Output Voltage Options Single Single Single Single
Dimensions 189x 61.5x 36.8 189x 61.5x 36.8 189x 61.5x 36.8 189x 61.5x 36.8
Working Temperature -40~+80°C (Refer to "Derating Curve")
Safety Standards UL8750, CSA C22.2 No. 250.0-13, ENEC EN61347-1, EN61347-2-13, EN62384, independent, IP67 approved
EMC Standards Compliance to EN55015, EN61000-3-2 Class C (b '60% load) ; EN61000-3-3, FCC part 15 class B, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A
