HVGC-320-B Series Non-dim Constant Current LED Drivers 300–320W

Download Datasheet
Models:
  • HVGC-320-700B
  • HVGC-320-1050B
  • HVGC-320-1400B
  • HVGC-320-1750B
  • HVGC-320-2100B
  • HVGC-320-2800B
  • HVGC-320-3500B
Manufacturer: Mean Well
Type: Constant Current LED Drivers

HVGC-320-B Series Features:

Wide input range 180~528VAC

High efficiency up to 91%

Built-in active PFC function

Protections: Short circuit / Over current / Over voltage / Over temperature

Other features:

  • Constant current design
  • Cooling by free air convection
  • Output voltage and CC level can be adjusted through internal potentiometer
  • IP65 design for indoor or outdoor installations
  • Suitable for LED lighting and street lighting applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry / damp / wet locations
  • 5 years warranty
Wattage 300 320 320 320 320 320 320
Input Voltage 180~528VAC 254VDC~747VDC 180~528VAC 254VDC~747VDC 180~528VAC 254VDC~747VDC 180~528VAC 254VDC~747VDC 180~528VAC 254VDC~747VDC 180~528VAC 254VDC~747VDC 180~528VAC 254VDC~747VDC
Output Current 700mA 1050mA 1400mA 1750mA 2100mA 2800mA 3500mA
Output Voltage Options Single Single Single Single Single Single Single
Dimensions 262x 90x 43.8 262x 90x 43.8 262x 90x 43.8 262x 90x 43.8 262x 90x 43.8 262x 90x 43.8 262x 90x 43.8
Working Temperature -40~+90°C (Refer to "Derating Curve")
Safety Standards UL8750 (type ???HL???), CSA C22.2 No. 250. 13-12, IP65 or IP67 approved
EMC Standards Compliance to FCC Part 15 Subpart B, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (Surge immunity Line-Earth 4KV, Line-Line 2KV) Criteria A
