MEAN WELL MEAN WELL logo

HLG-185H-CB Series 0-10V Dimmable Constant Current LED Drivers 200W

Download Datasheet
Models:
  • HLG-185H-C500B
  • HLG-185H-C700B
  • HLG-185H-C1050B
  • HLG-185H-C1400B
Manufacturer: MEAN WELL
Type: Constant Current LED Drivers

HLG-185H-CB Series Features:

Constant current design

Output voltage and C.C level can be adjusted through output cable

Protections: Short circuit / Over current / Over voltage / Over temperature

Other features:

  • Three in one dimming function (1~10Vdc or 10V PWM signal or resistance)
  • Universal AC input (up to 305VAC) / Full range
  • IP67 design for indoor or outdoor installations
  • High efficiency up to 94%
  • Cooling by free air convection
  • Built-in active PFC function
  • 7 years warranty
Wattage 200 200 200 200
Input Voltage 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC
Output Current 500mA 700mA 1050mA 1400mA
Output Voltage Options Single Single Single Single
Dimensions 228x 68x 38.8 228x 68x 38.8 228x 68x 38.8 228x 68x 38.8
Working Temperature -40~+70°C (Refer to "Derating Curve")
Safety Standards UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13, EN62384 independent, IP67 approved
EMC Standards Compliance to EN55015, EN61000-3-2 Class C (B!C
