Eaglerise FLS-44-1050 DALI2 LS DALI Dimmable Constant Current LED Drivers

Download Datasheet
Models:
  • FLS-44-1050 DALI2 LS
Manufacturer: Eaglerise
Type: Constant Current LED Drivers

FLS-44-1050 DALI2 LS Features:

FLS-44-1050 DALI2 LS is a 44W constant current, 2 slots LED driver with 700 to 1050mA output current and a forward

voltage range from 9 to 52Vdc. The output current is selectable by DIP Switch. With it’s dimensions from 180 x 80 x 30mm it

is easy to integrate in LED Panel, spot and down light products.

■Features
 Class II, SELV,independent
 Input Voltage 220-240VAC
 Protections: SCP/OLP/OVP
 Power Factor λ=0.97
 Efficiency ≥87%
 2 Slots
 Support DALI II, Push Dimming
 5 years warranty

Working Temperature -20~+45°C
Safety Standards EN 61347-1; EN61347-2-13; EN62384
EMC Standards EN55015; EN61000-3-2 Class C; EN61000-3-3
