MPM-10 Series Open Frame Power Supplies 8.3–10.2W

Download Datasheet
Models:
  • MPM-10-3.3
  • MPM-10-5
  • MPM-10-12
  • MPM-10-15
  • MPM-10-24
Manufacturer: Mean Well
Type: Open Frame Power Supplies

MPM-10 Series Features:

Medical safety approved (2x MOPP) according to ANSI/AAMI ES60601-1 and IEC/EN60601-1

No load power consumption <0.075W

Wide operating temp range -30~+85°C

Protections: Short circuit / Overload / Over voltage

Other features:

  • 1.8bx1b compact size
  • Suitable for BF application with appropriate system consideration
  • Extremely low leakage current
  • EMI class B for class II configuration
  • 3 years warranty
Wattage 8.3 10 10.2 10 10
Input Voltage 80-264VAC 80-264VAC 80-264VAC 80-264VAC 80-264VAC
Output Current 2.5A 2A 0.85A 0.67A 0.42A
Output Voltage 3.3 5 12 15 24
Output Voltage Options Single Single Single Single Single
Dimensions 45.7x 25.4x 21.5 45.7x 25.4x 21.5 45.7x 25.4x 21.5 45.7x 25.4x 21.5 45.7x 25.4x 21.5
Working Temperature -30-+85°C
Safety Standards IEC60601-1, EN60601-1, ULANSI/AAMI ES60601-1(3.1 version), CAN/CSA-C22 3rd Edition approved; Design refer to EN60335-1
EMC Standards EN55011, EN61000-3-2,3, EN55024, EN60601-1-2, EN61204-3 EN61000-4-2,3,4,5,6,8,11
