| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Open Frame Power Supplies |
Medical safety approved (2x MOPP) according to ANSI/AAMI ES60601-1 and IEC/EN60601-1
No load power consumption <0.075W
Wide operating temp range -40~+85°C
Protections: Short circuit / Overload / Over voltage / Over temperature
Other features:
| Wattage | 4.1 | 5 | 5 | 5 | 5.5 |
| Input Voltage | 80-264VAC | 80-264VAC | 80-264VAC | 80-264VAC | 80-264VAC |
| Output Current | 1.25A | 1A | 0.42A | 0.33A | 0.23A |
| Output Voltage | 3.3 | 5 | 12 | 15 | 24 |
| Output Voltage Options | Single | Single | Single | Single | Single |
| Dimensions | 42x 22.3x 20.5 | 42x 22.3x 20.5 | 42x 22.3x 20.5 | 42x 22.3x 20.5 | 42x 22.3x 20.5 |
| Working Temperature | -40-+85°C | ||||
| Safety Standards | IEC60601-1, EN60601-1, ULANSI/AAMI ES60601-1(3.1 version), CAN/CSA-C22 3rd Edition approved; Design refer to EN60335-1 | ||||
| EMC Standards | EN55011, EN61000-3-2,3, EN55024, EN60601-1-2, EN61204-3 EN61000-4-2,3,4,5,6,8,11 | ||||
