| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Open Frame Power Supplies |
100% full load burn-in test
Protections: Short circuit / Over load / Over Voltage
Other features:
| Wattage | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Input Voltage | 85~264VAC | 85-264VAC | 85-264VAC | 85-264VAC | 85-264VAC | 85-264VAC | 90~264VAC | 85-264VAC | 85-264VAC |
| Output Current | 0~20 | 0~20 | 0~13.5 | 0~12.5 | 0~7.5 | 0~6.7 | 0~4.2 | 0~3.8 | 0~2.1 |
| Output Voltage | 3.3 | 5 | 7.5 | 12 | 13.5 | 15 | 24 | 27 | 48 |
| Output Voltage Options | Single | Single | Single | Single | Single | Single | Single | Single | Single |
| DC output adjustment | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | +- 10% rated output voltage | -5%~+10% rated output voltage |
| Dimensions | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 | 222 x 62 x 32 |
| Working Temperature | -20~+70°C | ||||||||
| Safety Standards | UL60950-1, TUV EN60950-1 approved | ||||||||
| EMC Standards | EN55022 class B,EN61000-3-2,-3 , EN61000- 4-2,3,4,5,6,8,11 | ||||||||
