IRM-15 Series Open Frame Power Supplies 12–15W

IRM-15 Series Features:

No load power consumption <0.1W

Compact size

Protections: Short circuit/ Overload/ Over voltage

Other features:

Spec	IRM-15-3.3	IRM-15-5	IRM-15-12	IRM-15-15	IRM-15-24
Wattage	12	15	15	15	15
Input Voltage	90~305VAC, 120~370VDC	90~305VAC, 120~370VDC	90~305VAC, 120~370VDC	90~305VAC, 120~370VDC	90~305VAC, 120~370VDC
Output Current	0~3.5	0~3.0	0~1.25	0~1.0	0~0.63
Output Voltage	3.3	5	12	15	24
Output Voltage Options	Single	Single	Single	Single	Single
Dimensions	52.4x 27.2x 24	52.4x 27.2x 24	52.4x 27.2x 24	52.4x 27.2x 24	52.4x 27.2x 24
Working Temperature	-40~+85°C
Safety Standards	UL60950-1, TUV EN60950-1 approved
EMC Standards	Compliance to to EN55022 (CISPR22) Class B, EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level, criteria A
