| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Medical Grade Power Supplies |
Low leakage current <200uA
Protections: Short circuit / Overload / Over voltage
Other Features:
| Wattage | 75 | 75 | 75 | 75 | 75 |
| Input Voltage | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC |
| Output Current | 0.6~8.0, 0.2~4.0, 0.1~1.0 | 0.6~8.0, 0.2~4.0, 0.1~1.0 | 0.6~8.0, 0.1~3.0, 0.1~1.0 | 0.7~7.0, 0.0~8.0, 0.0~1.5 | 0.7~7.0, 0.0~8.0, 0.0~1.5 |
| Output Voltage | 5, 12, -5 | 5, 12, -12 | 5, 15, -15 | 5, 15, -15 | 3.3, 5, 12 |
| Output Voltage Options | Triple | Triple | Triple | Triple | Triple |
| DC output adjustment | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage | -5%~+10% rated output voltage |
| Dimensions | 127 x 76.2 x 31 | 127 x 76.2 x 31 | 127 x 76.2 x 31 | 127 x 76.2 x 31 | 127 x 76.2 x 31 |
| Working Temperature | -20~+70°C | ||||
| Safety Standards | UL60601-1, TUV EN60601-1 approved | ||||
| EMC Standards | EN55011, EN55022 Class B, EN6100-3-2,3 EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-1-2, EN61204-3 Medical level | ||||
