| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Medical Grade Power Supplies |
Built-in active PFC function
Protections: Short circuit / Overload / Over voltage
Other Features:
| Wattage | 160 | 160 | 160 | 160 |
| Input Voltage | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC |
| Output Current | 0.6~14, 0.2~5.5, 0.1~1.0 | 0.6~14, 0.2~5.0, 0.1~1.0 | 0.6~14, 0.1~3.6, 0.1~1.0 | 0.3~11, 0.2~5.0, 0.15~1.2 |
| Output Voltage | 5, 12, -5 | 5, 12, -12 | 5, 15, -15 | 5, 12, 24 |
| Output Voltage Options | Triple | Triple | Triple | Triple |
| DC output adjustment | +/- 10% rated output voltage | +/- 10% rated output voltage | +/- 10% rated output voltage | +/- 10% rated output voltage |
| Dimensions | 127 x 76.2 x 33 | 127 x 76.2 x 33 | 127 x 76.2 x 33 | 127 x 76.2 x 33 |
| Working Temperature | -20~+70°C | |||
| Safety Standards | UL60601-1, TUV EN60601-1 approved | |||
| EMC Standards | EN55011, EN55022 Class B, EN6100-3-2,3 EN61000-4-2,3,4,5,6,8,11, EN60601-1-2 | |||
