| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Medical Grade Power Supplies |
No load power consumption under 0.75W by PS-ON control
Protections: Short circuit / Overload / Over voltage
Other Features:
| Wattage | 160 | 160 | 160 | 160 | 160 | |
| Input Voltage | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC | |
| Output Current | 0~30 | 0~12.9 | 0~10.3 | 0~6.5 | 0~3.25 | |
| Output Voltage | 5 | 12 | 15 | 24 | 48 | |
| Output Voltage Options | Single | Single | Single | Single | Single | |
| DC output adjustment | +/- 10% rated output voltage | +/- 10% rated output voltage | +/- 10% rated output voltage | +/- 10% rated output voltage | +/- 10% rated output voltage | |
| Dimensions | 127 x 76.2 x 33 | 127 x 76.2 x 33 | 127 x 76.2 x 33 | 127 x 76.2 x 33 | 127 x 76.2 x 33 | |
| Working Temperature | -25~+70°C | |||||
| Safety Standards | UL60601-1, TUV EN60601-1 approved | |||||
| EMC Standards | EN55011, EN55022 Class B, EN6100-3-2,3 EN61000-4-2,3,4,5,6,8,11, EN60601-1-2 | EN55011, EN55022 Class B, EN6100-3-2,3 EN61000-4-2,3,4,5,6,8,11, EN60601-1-2, EN61000-6-2 | ||||
