EUCHIPS EUCHIPS logo

EUP40A Series 0-10V Dimmable Constant Voltage LED Drivers 40W

Download Datasheet
Models:
  • EUP40A-1HMC-1
  • EUP40A-1W12V-1
  • EUP40A-1W24V-1
Manufacturer: EUCHIPS
Type: Constant Voltage LED Drivers

EUP40A Series Features:

Single channel constant voltage output

Support 3-in-1 dimming function(Active signal, adjustable resistance, PWM)

Other features:

  • Dimming range from 0-100%
  • Wide input voltage of 100VAC ~ 240VAC
  • High efficiency up to 86%
  • 100% output when no dimming signal input, can be used as normal power supply
  • Dimming effect smooth, no flicker
  • Over load protection ,short circuit protection
  • Suitable for indoor LED lighting application
Wattage 40 40 40
Input Voltage 220-240VAC 100-240VAC 100-240VAC
Output Current 850,900,950,1000,1050,1100,1150,1200mA 3.4A 1.7A
Output Voltage 9-45VDC 12V 24V
Output Voltage Options Single Single Single
Dimensions 137 x 82 x 31 137 x 82 x 31 137 x 82 x 31
Working Temperature -20 - +40°C
Safety Standards CE
