| Models: |
|
| Manufacturer: | ELED |
| Type: | Constant Voltage LED Drivers |
Three in one dimming function (0/1-10Vdc or PWM signal or resistance)
IP66 design for indoor or outdoor installation
Protections: Short circuit/ Over Current/ Over Temperature / Over Loading
Other features:
| Wattage | 60 | 60 |
| Input Voltage | 100-265VAC | 100-265VAC |
| Output Current | 5A | 2.5A |
| Output Voltage | 12 | 24 |
| Output Voltage Options | Single | Single |
| DC output adjustment | N/A | N/A |
| Dimensions | 200x 70x 46 | 200x 70x 46 |
| Working Temperature | -40~+60°C | |
| Safety Standards | EN61347-1, EN61347-2-13 | |
| EMC Standards | Compliance to EN55015, EN61000-3-2 (>60% load) Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry level (surge 4KV) Criteria A | |
