LDD-1500L Series Non-dim Constant Current LED Drivers 10–69W

Models:	LDD-300L LDD-350L LDD-500L LDD-600L LDD-700L LDD-1000L LDD-1200L LDD-1500L
Manufacturer:	MEAN WELL
Type:	Constant Current LED Drivers

LDD-1500L Series Features:

Built-in PWM dimming control

Cooling by free air convection

Wide input and output voltage range

Protections: Short circuit / Over temperature

Other features:

Constant current LED driver
High efficiency up to 97%
Comply with EN55015 and FCC part 15 without additional input filter and capacitors
Compact size
Fully enclosed plastic case (UL 94V-0)
Low cost, high reliability
3 years warranty

Spec	LDD-300L	LDD-350L	LDD-500L	LDD-600L	LDD-700L	LDD-1000L	LDD-1200L	LDD-1500L
Wattage	10	10	16	19	22	52	55.2	69
Input Voltage	9~36VDC	9~36VDC	9~36VDC	9~36VDC	9~36VDC	6~36VDC	6~36VDC	6~36VDC
Output Voltage	30	30	30	30	30	-2	-2	-2
Output Voltage Options	Single	Single	Single	Single	Single	Single	Single	Single
Dimensions	22.6x 9.9x 8.9	22.6x 9.9x 8.9	22.6x 9.9x 8.9	22.6x 9.9x 8.9	22.6x 9.9x 8.9	31.8x 20.3x 12.2	31.8x 20.3x 12.2	31.8x 20.3x 12.2
Working Temperature	-40~+71°C
EMC Standards	Compliance to EN55015, FCC part 15 class B Compliance to EN61000-4-2,3,4,6,8, light industry level, criteria A
