DRA-40 Series DIN Rail Power Supplies 40.08–40.8W

Download Datasheet
Models:
  • DRA-40-12
  • DRA-40-24
Manufacturer: Mean Well
Type: DIN Rail Power Supplies

DRA-40 Series Features:

DRA-40 is one 40W AC/DC DIN rail power supply, featuring the adjustable output current. Users are able to easily change the constant output current level, via 1 ~ 10 Vdc, PWM signal or resistance.

Features:

  • Universal AC input/full range
  • Protections: short circuit / Overload / Over voltage
  • Can be installed on DIN rail TS-35/7.5 or 15
  • Output voltage adjustable through internal potentiometer
  • Output current adjustable through external 1 ~ 10Vdc, PWM signal or resistance
  • Cooling by free air convection
  • Pass LPS
  • LED indicator for power on
  • 100% full load burn-in test
  • 3 years warranty
Wattage 40.08 40.8
Input Voltage 90~264 VAC 127~370VDC 90~264 VAC 127~370VDC
Output Current 3.34A 1.7A
Output Voltage 12V 24V
Output Voltage Options 12 ~ 15V 3~24V
Dimensions 40*90*100MM (W*H*D) 40*90*100MM (W*H*D)
Working Temperature -30~+70°C
Safety Standards UL62368-1, TUV EN62368-1, WAC TP TC 004 approved
EMC Standards Compliance to EN55032(CISPR32) Class B, EN61000-3-2, -3, EAC TP TC 020
