Mean Well DDR-120 Series DIN Rail Power Supplies 99.6–120W

Download Datasheet
Models:
  • DDR-120A-12
  • DDR-120A-24
  • DDR-120A-48
  • DDR-120B-12
  • DDR-120B-24
  • DDR-120B-48
  • DDR-120C-12
  • DDR-120C-24
  • DDR-120C-48
  • DDR-120D-12
  • DDR-120D-24
  • DDR-120D-48
Manufacturer: Mean Well
Type: DIN Rail Power Supplies

DDR-120 Series Features:

Can be installed on DIN rail TS-35/7.5 or 15

Protections: Short circuit/ Overload/ Over voltage/ Input reverse polarity/ Input under voltage protection

Other features:

  • Compliance to EN50155 and EN45545-2 railway standard
  • Width only 32mm
  • 2:1 wide input range
  • 150% peak load capability
  • DC output adjustable
  • Cooling by free air convection
  • 4KVdc I/O isolation (Reinforced isolation)
  • -40~+70B0C wide working temperature
  • 3 years warranty
Wattage 99.6 100.8 100.8 120 120 120 120 120 120 120 120 120
Output Current 0-8.3A 0-4.2A 0-2.1A 0-10A 0-5A 0-2.5A 0-10A 0-5A 0-2.5A 0-10A 0-5A 0-2.5A
Output Voltage 5 24 48 5 24 48 5 24 48 5 24 48
Output Voltage Options Single Single Single Single Single Single Single Single Single Single Single Single
DC output adjustment 9-14V 24-28V 48-56V 9-14V 24-28V 48-56V 9-14V 24-28V 48-56V 9-14V 24-28V 48-56V
Dimensions 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102 32x 125.2x 102
Working Temperature -40B0C-+70B0C
Safety Standards IEC 62368-1 (LVD) approved, Design refer to UL508
EMC Standards Compliance to EN55032, EN61000-3-3. Compliance to EN55024, EN61000-6-2 (EN50082-2), EN61000-4-2,3,4,5,6,8
