Mean Well LED Driver HLG-240H-36A 240W 36V

Download Datasheet

Mean Well LED Driver HLG-240H-36A 240W 36V Features:

Output voltage and C.C level can be adjusted through internal potentiometer

IP65 design for indoor or outdoor installations

Protections: Short circuit / Over current / Over voltage / Over temperature

Other features:

  • Universal AC input (up to 305VAC) / Full range
  • High efficiency up to 95%
  • Output current adjustable through output cable or internal potentiometer
  • Cooling by free air convection
  • Suitable for LED lighting and street lighting applications
  • Meet 4KV surge immunity level (IEC61000-4-5)
  • Multiple models for choice:
  • Built-in active PFC function, PF>0.9 for 60% of load or higher
  • Optional CQC models available
  • 5 years warranty
Wattage 240
Input Voltage 90~305VAC, 127~431VDC
Output Current 0~6.70
Output Voltage Options Single
DC output adjustment +/-6% rated output voltage
Working Temperature -40~+70B0C
Safety Standards UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13, UL1012, UL60950-1, TUV EN60950-1
Dimensions 244.2 x 68 x 38.8
