| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Constant Voltage LED Drivers |
Fully encapsulated with IP67 level
Protections: Short circuit/ Over Current/ Over voltage/ Over temperature
Other features:
| Wattage | 120 | 120 | 120 | 120 | 120 | 120 | 120 |
| Input Voltage | 90-305VAC | 90-305VAC | 90-305VAC | 90-305VAC | 90-305VAC | 90-305VAC | 90-305VAC |
| Output Voltage | 20 | 24 | 30 | 36 | 42 | 48 | 54 |
| Output Voltage Options | Single | Single | Single | Single | Single | Single | Single |
| DC output adjustment | 12-20V | 14.4-24V | 18-30V | 21.6-36V | 25.2-42V | 28.8-48V | 32.4-54V |
| Dimensions | 191x 63x 37.5 | 191x 63x 37.5 | 191x 63x 37.5 | 191x 63x 37.5 | 191x 63x 37.5 | 191x 63x 37.5 | 191x 63x 37.5 |
| Working Temperature | -40-+80°C | ||||||
| Safety Standards | UL8750, CSA C22.2 No. 250. 13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67 approved; Design refer to EN60335-1 | ||||||
| EMC Standards | Compliance to EN55015, EN61000-3-2 Class C (>60% load) ; EN61000-3-3, Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level(surge 2KV), criteria A. | ||||||
