| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Constant Voltage LED Drivers |
IP67 design for indoor or outdoor installations
Built-in active PFC, PF>0.9 for 60% of load or higher
7 years warranty
Protections: Short circuit / Over current / Over voltage / Over temperature
Other features:
| Wattage | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
| Input Voltage | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC | 90~305VAC, 127~431VDC |
| Output Voltage | 12 | 15 | 20 | 24 | 30 | 36 | 42 | 48 | 54 |
| Output Voltage Options | Single | Single | Single | Single | Single | Single | Single | Single | Single |
| DC output adjustment | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| Working Temperature | -40~+70°C (Refer to "Derating Curve") | ||||||||
| Safety Standards | UL8750, TUV EN61347-1, EN61347-2-13 approved; Design refer to UL60950-1, EN60950-1, EN60335-1 | ||||||||
| EMC Standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 | ||||||||
