Models: |
|
Manufacturer: | MEAN WELL |
Type: | Constant Voltage LED Drivers |
Constant Voltage
Fully isolated plastic case
Protections: Short circuit/ Overload/ Over voltage
Other features:
Wattage | 13 | 15 | 15 | 16 |
Input Voltage | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC |
Output Voltage | 5 | 12 | 12 | 24 |
Output Voltage Options | Single | Single | Single | Single |
DC output adjustment | N/A | N/A | N/A | N/A |
Dimensions | 77 x 40 x 29 | 77 x 40 x 29 | 77 x 40 x 29 | 77 x 40 x 29 |
Working Temperature | -30~+70°C (Refer to "Derating Curve") | |||
Safety Standards | Design refer to TUV EN60950-1, EN61347-2-13, UL8750 | |||
EMC Standards | EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 |
