| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Constant Voltage LED Drivers |
Constant Current
Fully isolated plastic case
Protections: Short circuit
Other features:
| Wattage | 10 | 12 | 12 | 12 |
| Input Voltage | 180~264VAC; 254~370VDC | 180~264VAC; 254~370VDC | 180~264VAC; 254~370VDC | 180~264VAC; 254~370VDC |
| Output Voltage | 5 | 12 | 15 | 24 |
| Output Voltage Options | Single | Single | Single | Single |
| Dimensions | 77 x 40 x 29 | 77 x 40 x 29 | 77 x 40 x 29 | 77 x 40 x 29 |
| Working Temperature | -30~+70°C | |||
| Safety Standards | IP42 approved; design refer to EN61347-1, EN61347-2-13 | |||
| EMC Standards | EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A | |||
